> >IEC 61169-66 Ed. 1.0 b:2021
Reduced price! IEC 61169-66 Ed. 1.0 b:2021 View larger

IEC 61169-66 Ed. 1.0 b:2021

M00013998

New product

IEC 61169-66 Ed. 1.0 b:2021 Radio-frequency connectors - Part 66: Sectional specification for RF coaxial connectors with 5 mm inner diameter of outer conductor, with quick-lock- or screw-coupling, characteristic impedance 50 Omega (series 2,2-5)

standard by International Electrotechnical Commission, 02/23/2021

More details

In stock

$113.96

-56%

$259.00

More info

Full Description

IEC 61169-66:2021 provides information and rules for the preparation of detail specifications (DS) for series 2,2-5 RF coaxial connectors with quick-lock- or screw coupling, characteristic impedance 50, for operating frequencies up to 6 GHz. Typical use is in wireless telecommunication systems. It describes mating face dimensions for general purpose connectors - grade 2, gauging information and tests selected from IEC 61169-1, applicable to all detail specifications relating to series 2,2-5 RF connectors. This specification indicates recommended performance characteristics to be considered when writing a detail specification and it covers test schedules and inspection requirements for assessment levels M and H.

Product Details

Edition: 1.0 Published: 02/23/2021 Number of Pages: 61 File Size: 1 file , 3.5 MB
